LT-water tank wire drawing machine
This equipment is designed for spring wires and other small size wires. The drawing process is in the special liquid, reduce the heat produced by the drawing. To sure the quality and specifications of wire according to the requirement.
Main Specification:
technica unit LT-9/550 LT-11/450 LT-15/350 LT-11/250 Block dia mm 550 450 350 250 Quantity of dies 9 11 15 15 Input dia mm 3.2-5.6 3.8-4.0 2.8 1.7 Output dia mm 1.4-3.0 1.5-1.6 0.6-0.8 0.4-0.6 Total condensatin ％ 80 84 91 88 Average consendation ％ 18.25 15 15 15 Max speed m/s 4.17 6 7 7 Motor power kw 132 75 30-45 18.5-22 Overall dimension cm 598×350×184 578×330×164 260×130×125 240×130×135 weight kg 14000 9000 2650 2400
